全自动恒温膏体灌装机



适合粘度较大，流动性较差的膏体物料的计量灌装。采用气动灌装，料斗和料缸、出料管道均用电加热，料斗配有一框式搅拌系统。清洗、操作方便，符合GMP标准。



特点



1、本机配圆柱形料箱，夹层电加温，有划桨搅拌装置，可对膏液体物料加热、搅拌、温控等功能，可以让需要加热、搅拌、恒温的物料在规定的范围内灌装，达到预定的效果 ；
2、本机灌装采用压缩空气控制，双头双线，光标定位刹车形式，速度比挡瓶形式明显提高；



3、气动部分采用台湾AirTac的气动元件；



4、物料接触部分采用316L不锈钢制成，符合GMP要求；



5、有灌装量调节手柄，灌装速度可任意调节，灌装精确度高；



6、灌装闷头采用防滴漏、防拉丝及升降灌装装置。



7、物料从料斗到灌装嘴出料端采用发热丝保温；



8、机器底部装脚装、移动方便
9、本机设计合理，结构紧凑，操作简单易用，故障率低。



技术参数：



1、灌装范围：5-150（ml）(可按照用户要求定做）



2、料斗容量：30，40，50（L）



3、料斗材质：与物料接触面（内层）316L不锈钢，夹层为SUS304不锈钢



3、生产能力：0-25（次/分）



4、使用温度：0-95℃



5、驱动压力：0.2-0.45（mpa）



6、搅拌系统10-60转



7、搅拌功率：60w



8、外形尺寸（约）：550×400×1900

Single head automatic thermostat paste filling machine
Suitable viscosity, less liquid metering paste filling material.Pneumatic filling, hopper and tank, electric discharge pipes are heated hopper with a box-type mixing system.Cleaning, easy to operate, meet the GMP standard.
Feature
Within the range of 1, the machine is equipped with a cylindrical tank, electric heating mezzanine with paddle stirring device, the material can be heated to a liquid paste, stirring, temperature control and other functions, can make need to be heated, stirring, temperature of the material in the prescribedfilling, to achieve the desired effect;
2, the machine uses compressed air to control the filling, double double, cursor positioning brake form faster than the bottle in the form of block significantly improved;
3, the pneumatic part adopts Taiwan AirTac pneumatic components;
4, material contact parts made of 316L stainless steel, meet the GMP requirements;
5, there are adjustment handle of filling volume, the filling speed can be adjusted, filling accuracy;
6 Filling head adopts anti-leakage, anti-pull and lifting filling device.
7, the material from the hopper to the filling nozzle discharge end uses heating wire insulation;
8, bottom mounted machine foot wear, easy to move
9, the machine reasonable design, compact structure, simple-to-use, low failure rate.
Technical parameters:
1, Filling range :5-150 (ml) (can be customized according to user requirements)
2, Hopper capacity: 30,40,50 (L)
3, Hopper Material: The material contact surface (inner) 316L stainless steel, laminated to SUS304 stainless steel
4, the production capacity :0-25 (beats / min)
5, temperature :0-95 ℃
6, the driving pressure :0.2-0 .45 (mpa)
7, 10-60 rpm mixing system
8, the stirring power: 60w
9, Dimensions (approximately): 550 × 400 × 1900
